Data Akurat

Memberikan informasi secara otomatis dan real-time.

Dapat terhubung dengan aplikasi lain

Mudah diintegrasikan dengan pemasangan sensor pada kendaraan.

Penanganan dari jauh

Mudah mengendalikan kendaraan dengan matikan/hidupkan mesin dari jarak jauh.

GNSS

GPS, GLONASS, GALILEO, BEIDOU, QZSS, AGPS

Receiver

33 channel

Position Accuracy

< 2.5 m CEP

Hot start

< 1 s

Warm start

< 25 s

Cold start

< 35 s

Technology

GSM

2G bands

Quad-band 850 / 900 / 1800 / 1900 MHz

Data transfer

GPRS Multi-Slot Class 12 (up to 240 kbps), GPRS Mobile Station Class B

Input voltage range

10–30 V DC with overvoltage and reverse polarity protection

Internal Back-up battery

170 mAh Li-Ion battery, 3.7 V (0.63 Wh)

Bluetooth Specification

4.0 + LE

Supported peripherals

Temperature and Humidity sensor, Headset, OBDII dongle, Inateck Barcode Scanner, Universal BLE sensors support

Dimensions

65 x 56,6 x 20,6 mm (L x W x H)

Weight

55 g

Operating temperature (without battery)

-40 °C to +85 °C

Storage temperature (without battery)

-40 °C to +85 °C

Operating humidity

5% to 95% non-condensing

Ingress Protection Rating

IP41

Battery charge temperature

0 °C to +45 °C

Battery discharge temperature

-20 °C to +60 °C

Battery storage temperature

-20 °C to +45 °C for 1 month
-20 °C to +35 °C for 6 months

Digital Inputs

3

Digital Outputs

3

Negative Inputs

1 (Digital Input 2)

Impuls Inputs

2 (Digital Input 1, Digital Input 2)

Analog Inputs

2

CAN Adapter Inputs

1

1-Wire

1

GNSS antenna

Internal High Gain

Cellular antenna

Internal GSM High Gain

USB

2.0 Micro-USB

LED indication

2 status LED lights

SIM

Micro-SIM or eSIM

Memory

128MB internal flash memory
